- Safe LiFePO₄ battery – liquid cooling and heating film for reliable operation (–30 °C ~ +55 °C)
- Smart BMS with full protection and real-time monitoring
- Direct motor drive + braking energy recovery for high efficiency and energy savings (~13 %)
- 600 V high-voltage system supporting dual-gun fast charging for multi-shift operation
- Integrated thermal management utilizing motor and A/C waste heat for enhanced performance
- Intelligent monitoring system with real-time data display, diagnostics, and fault alerts
- Rated Capacity: 10 – 25 t
- Overall Weight: 13 500 – 33 500 kg
- Lift Height (standard): 3 000 – 4 000 mm
- Lift Speed (laden / unladen): 320 – 500 mm s⁻¹
- Travel Speed (laden / unladen): 22 – 25 km h⁻¹
- Gradeability (laden): 15 – 27 %
- Battery: LiFePO₄ 521 – 618 V / 90 – 282 kWh
- Drive / Pump Motor: 105 – 130 kW / 63 – 120 kW
- Fork Size (L × W × T): 1500 – 2440 × 200 × 75 – 110 mm
- Turning Radius: 4 000 – 6 000 mm
