- Fully electric operation with lithium iron phosphate battery pack (422/507 kWh)
- Rated load capacity: 45 t, stack up to 5 containers high
- Max lift height: 15,100 mm, boom elevation 0–60°
- PMSM electric motor with 157 kW rated / 310 kW peak output
- Quick 90-min charging, 6–8 h endurance time
- EU CE and EMC certified, with high-voltage interlock safety monitoring
- Optional CCS1/CCS2 charging ports for different regions
- Battery: Lithium iron phosphate, 618 V, heating & water cooling
- Motor: PMSM, 1500 Nm torque rated / 4200 Nm peak, water cooling
- Rated Load: 45 t
- Max Lifting Speed: 420 mm/s (unladen) / 250 mm/s (laden)
- Max Traveling Speed: 20 km/h (unladen) / 14 km/h (laden)
- Hydraulic Pressure: 340 bar
- Overall Weight: 73 t
- Wheelbase: 6,000 mm
- Overall Dimensions (L × W): 11,320 mm × 6,053–12,185 mm
- Ground Clearance: 330 mm
- Min Turning Radius: 8,000 mm
