- Heavy-Duty Handling: 45 t rated load capacity, 5-high container stacking
- Powerful Performance: Volvo TAD1181VE engine, 265 kW, 1795–1400 Nm torque
- Flexible Operation: ±800 mm lateral move, 105°–195° rotation, ±5° tilt angle
- Reliable Components: Parker main valve & pump, Kessler D102 drive axle
- High Mobility: 25 km/h loaded, 21 km/h unloaded, 8 m min turning radius
- Rated Load: 45 t
- Max Lift Height: 15,100 mm
- Stack Layer: 5
- Max Boom Elevation: 0–60°
- Overall Length: 11,320 mm
- Wheelbase: 6,042 mm
- Overall Width: 6,053–12,185 mm
- Turning Radius: 8,000 mm
- Ground Clearance: 350 mm
- Tires: 18.00–25
- Weight: 72.5 t (machine), 7.1 t (spreader)
- Suitable Containers: ISO 20’/40’/45′
